HSS-20

• Operates upto twenty samples continuously
• Indication on display for live operation mode
• Separate keyboard & display for head space activity


Model Name    : Head Space Sampler HSS-20

Type    : Static

Vial Size    : 20 ml

No. of vials    : 20

Sample Loop    : 1 ml

Vial temperature range    : Ambient to 250oC, settable

Programme    : 1 to 20 vials, or settable

Valving    : Motorized 6 port valve

Valve /Loop temperature    : Automatically gets adjusted with Vial Temperature

Sample path    : 1/16” silynated s.s

Transfer Line Temperature    : Ambient to 250oC, Settable

Electronic control    : Parameters entry via GC front Panel

Physical dimensions    : 35.0 cm W x 31.0 cm L x 32 cm H

Display    : LCD with backlit, 4 Lines x 20 Characters

Key Board    : Membrane

Weight    : 10 Kg Approx.

Power requirements    : 230 V AC, 50 Hz supply.

Agrochemicals:
 Evaluation of technical & formulated material complying BIS & relevant bodies

API/BDI industries :
Estimation of residual solvents using HSS.
 Estimation of residual solvents using HSS.
 Control the quality of solvents/raw materials/reagents.
 To monitor the course of the reaction whenever possible.

Environmental:
 Monitoring the Bap content with other PAHs.
 Residual pesticides from drinking water.
 Monitor the Trihalomethane content of the ambient air.
 PCB content of the oil and water.
 Gaseous analysis of Hydrocarbon and permanent gases in ambient air

Petroleum & Refinery:
 Evaluation of quality of Petroleum based products

Perfume Industry:
 Fragrance composition

Food Industry:
 Composition of edible oils with respect to their MUFA,PUFA & SFA evaluation with focus on trans content

Petrochemicals:
 Evaluation of hydrocarbon blending in wax and other blends

Speciality Chemical Industry:

Research:
 Accomplish the special projects that are applicable.

Polymer:
 Evaluation of quality of raw materials in the form of monomers & detection of these monomers at trace levels in polymers

Packaging:
 Estimation of residual solvents from the packaging materials.

Solvent Industry:
 Evaluation of the quality of recoverd/distilled solvents

Beverages:
 Impurity profiling of alcohol produced
